CLUB3D CSV-2541 USB TYPE-C 12-IN-1 TRIPLE DISPLAY PORT REPLICATOR WITH 8K @30HZ HDMI AND PD3.0 MAX. 100W

Product Description

The CLUB3D CSV-2541 USB TYPE-C 12-IN-1 TRIPLE DISPLAY PORT REPLICATOR WITH 8K @30HZ HDMI AND PD3.0 MAX. 100W is a high-performance solution from CLUB3D, designed for professional and commercial applications. This product is built to meet rigorous industry standards, ensuring durability and seamless integration into professional environments.

Key Features:

• FEATURES
• Triple Display Support – Drive up to three displays from one connection (1× 4K @60Hz plus 2× 4K @30Hz)
• 8K and Dual 4K Output – Supports 8K @30Hz or dual 4K @60Hz
• Power Delivery 3.0 – up to 100W charging for laptop and devices
• Multiple Video Outputs – 2× HDMI and 1× DisplayPort for flexible display setups
• High-Speed USB Ports – USB Type-A and USB Type-C for everyday connectivity

Technical Specifications:
FEATURES

• Triple Display Support – Drive up to three displays from one connection (1× 4K @60Hz plus 2× 4K @30Hz)
• 8K and Dual 4K Output – Supports 8K @30Hz or dual 4K @60Hz
• Power Delivery 3.0 – up to 100W charging for laptop and devices
• Multiple Video Outputs – 2× HDMI and 1× DisplayPort for flexible display setups
• High-Speed USB Ports – USB Type-A and USB Type-C for everyday connectivity
• Gigabit Ethernet – Stable wired network up to 1Gbps
• SD and MicroSD Card Slots – Simultaneous access for fast file transfers
• Fast Role Swap – Prevents disconnection when unplugging power
• Ergonomic Design – Improves airflow and cable management for cleaner setups

SPECIFICATIONS

• Input:
 - 1× USB Type-C (Host, DP 1.4 Alt Mode)
• Output:
 - 2× HDMI
 - 1× DisplayPort 1.4
 - 1× USB Type-C PD
 - 3× USB Type-A (5Gbps)
 - 1× RJ45 Ethernet (10/100/1000Mbps)
 - 1× SD Card Slot
 - 1× MicroSD Card Slot
 - 1× 3.5mm Audio Jack
• Video Support:
 - up to 8K @30Hz
 - Dual 4K @60Hz
 - Triple Display: 4K @60Hz + 2× 4K @30Hz
 - DisplayPort 1.4 Alt Mode with DSC
 - HDR Support
 - HDCP 2.3 and HDCP 1.4
 - RGB and YCbCr Colour Formats (4:4:4 / 4:2:2 / 4:2:0)
 - 8-bit / 10-bit / 12-bit Colour Depth
• Data Transfer: USB3.2 Gen1 (5Gbps)
• Power Delivery:
 - PD 3.0 up to 100W
 - Fast Role Swap Support
 - Total USB Output up to 12W (5V 2.4A)
• Networking: Gigabit Ethernet (10/100/1000Mbps)
• Card Reader: SD and MicroSD (UHS-I, up to 104MB/s) Simultaneous Use
• OS Support: Windows 10 and Above
• Connector Dimensions (USB Type-C): 3.62 × 1.2 × 0.63cm
• Box Dimensions: 36.8 × 10.6 × 7.5cm
• Device Weight: 438g
• Total Weight: 950g
• Meets ROHS, FCC and CE EMI Requirements
