Lindy 3M USB3.2 TYPE-A TO MICRO-B CABLE – ANTHRA LINE (36768)

Product Description

The Lindy 3M USB3.2 TYPE-A TO MICRO-B CABLE – ANTHRA LINE (36768) is a high-performance solution from Lindy, designed for professional and commercial applications. This product is built to meet rigorous industry standards, ensuring durability and seamless integration into professional environments.

Key Features:

• FEATURES
• Professional choice USB3.2 Gen1 Type-A to Micro-B cable for commercial and high performance AV and IT installations
• SuperSpeed USB – Supports data transfer speeds up to 5Gbps
• Robust PVC housing, gold plated connectors and contacts
• Triple shielded cable, corrosion resistant tinned copper conductors
• CONNECTORS

Technical Specifications:
FEATURES

• Professional choice USB3.2 Gen1 Type-A to Micro-B cable for commercial and high performance AV and IT installations
• SuperSpeed USB – Supports data transfer speeds up to 5Gbps
• Robust PVC housing, gold plated connectors and contacts
• Triple shielded cable, corrosion resistant tinned copper conductors

CONNECTORS

• Connector A: USB3.2 Type-A Male
• Connector B: USB3.2 Micro-B Male
• Housing Material: PVC
• Connector Plating: Gold
• Pin Construction: Brass
• Pin Plating: Gold
• Dimensions (Approx.) W × D × H:
USB Type-A: 15.5 × 35 × 7.8mm
Micro-B: 15.8 × 26 × 7.8mm

CABLE CONSTRUCTION

• Colour: Black
• Jacket Diameter: 5.5mm
• Jacket Material: PVC
• Conductor Material: Tinned Copper
• Conductor Gauge Power: 24AWG
• Conductor Gauge Data: 28AWG
• Shielding: 80% Aluminium-Magnesium Braid

SPECIFICATIONS

• Nominal Attenuation: 0.5MHz~7.5GHz <25dB
• Minimum Bend Radius: 48mm
• Operating Temperature: 0~40°C
• Storage Temperature: 0~70°C
• Product Compliance: RoHS, REACH, California Proposition 65 & UL
