Mercusys 4G LTE 300MBPS ROUTER

Product Description

The Mercusys 4G LTE 300MBPS ROUTER is a high-performance solution from Mercusys, designed for professional and commercial applications. This product is built to meet rigorous industry standards, ensuring durability and seamless integration into professional environments.

Key Features:

• FEATURES
• 4G LTE Connectivity – Share internet access with up to 32× Wi-Fi devices and enjoy download speeds of up to 150Mbps
• Plug-and-Play Setup – Simply insert a SIM card to create your wireless network with no configuration required
• 300Mbps Wi-Fi Speeds – Provides fast 2.4GHz wireless connectivity for smooth browsing, streaming and everyday use
• Maximum Network Coverage – Four external antennas deliver stable connections and wider wireless coverage
• Flexible Router Mode – LAN/WAN port supports wired broadband connection when a 4G network is unavailable

Technical Specifications:
FEATURES

• 4G LTE Connectivity – Share internet access with up to 32× Wi-Fi devices and enjoy download speeds of up to 150Mbps
• Plug-and-Play Setup – Simply insert a SIM card to create your wireless network with no configuration required
• 300Mbps Wi-Fi Speeds – Provides fast 2.4GHz wireless connectivity for smooth browsing, streaming and everyday use
• Maximum Network Coverage – Four external antennas deliver stable connections and wider wireless coverage
• Flexible Router Mode – LAN/WAN port supports wired broadband connection when a 4G network is unavailable

SPECIFICATIONS

WIRELESS
• Network Type:
– FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700MHz)
– TDD-LTE: B38/B40 (2600/2300MHz)
– HSPA+/UMTS: B1/B5/B8 (2100/850/900MHz)

• Wi-Fi Class: N300
• Wi-Fi (2.4GHz): 300Mbps
• Wireless Standards: IEEE 802.11b/g/n
• Frequency: 2.4GHz

RECEPTION SENSITIVITY
• 11g 54M: -74.5dBm
• 11n HT20 MCS7: -73.5dBm
• 11n HT40 MCS7: -70.5dBm

TRANSMISSION POWER
• <20dBm (2.4GHz)

WIRELESS SECURITY
• WPA-PSK
• WPA2-PSK

WIRELESS FUNCTIONS
• Smart Connect
• WPS
• Wireless Schedule
• Wireless Clients Statistics

SOFTWARE

OPERATION MODES
• 3G/4G Router
• Wireless Router

CELLULAR MODE
• 4G Preferred
• 4G Only
• 3G Only

CELLULAR APN
• Data Roaming
• Network Search
• Profile Create
• APN Settings
• ISP File Upgrade
• PIN Management

WAN MODE
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP

DHCP
• Server
• DHCP Client List
• Address Reservation

NAT FORWARDING
• ALG
• Virtual Server
• Port Triggering
• UPnP
• DMZ

PROTOCOLS
• IPv4
• IPv6

DATA SETTINGS
• Data Statistics
• Data Limit

GUEST NETWORK
• 2.4GHz Guest Network

PARENTAL CONTROLS
• Time Control
• Website Filtering

DDNS
• Mercusys DDNS
• DynDNS
• NO-IP

SMS
• Inbox
• New Message
• Outbox
• Drafts

SECURITY
• IPv4 SPI Firewall
• Access Control
• Service Filtering
• IP and MAC Binding
• IPv6 Firewall

SYSTEM SETTINGS
• Time Settings
• LED Control
• Diagnostics
• Firmware Upgrade
• Backup and Restore
• Reboot
• Administration
• System Log
• CWMP Settings

DEVICE MANAGEMENT
• Mercusys App
• Web GUI

TR-069
• Supported

HARDWARE
• Dimensions (W × D × H): 219 × 140 × 32mm
• Interfaces:
– 1× 10/100Mbps LAN/WAN Port
– 3× 10/100Mbps LAN Ports
– 1× Nano SIM Card Slot
• Antenna:
– 2× External 4G LTE Antennas
– 2× External Wi-Fi Antennas
• Button: WPS / Reset Button
• External Power Supply: 9V 0.85A

LED
• Power
• Internet
• LAN
• Signal (3×)

LTE STANDARD
• CAT4
• 150Mbps Download / 50Mbps Upload

ENVIRONMENT
• Operating Temperature: 0~40°C
• Storage Temperature: -40~60°C
• Operating Humidity: 10~90% RH (Non-Condensing)
• Storage Humidity: 5~90% RH (Non-Condensing)
