SYNOLOGY RS2821RP+ 16-BAY, 4GB, QC, R PWR -DISKLES

Product Description

The SYNOLOGY RS2821RP+ 16-BAY, 4GB, QC, R PWR -DISKLES is a high-performance solution from SYNOLOGY, designed for professional and commercial applications. This product is built to meet rigorous industry standards, ensuring durability and seamless integration into professional environments.

Key Features:

• FEATURES
• High Performance – Supports critical workloads with up to 2,200MB/s read and 1,164MB/s write performance
• Redundant Power – Maximise uptime with two redundant power supply units
• Expansion Options – Scale up to 28× drives with the RX1217(RP) and add 10/25GbE networking or fast NVMe SSD Cache with PCIe add-on cards
• High Availability – Combine two devices into a Synology High Availability cluster for maximum service uptime and minute-level failover
• SPECIFICATIONS

Technical Specifications:
FEATURES

• High Performance – Supports critical workloads with up to 2,200MB/s read and 1,164MB/s write performance
• Redundant Power – Maximise uptime with two redundant power supply units
• Expansion Options – Scale up to 28× drives with the RX1217(RP) and add 10/25GbE networking or fast NVMe SSD Cache with PCIe add-on cards
• High Availability – Combine two devices into a Synology High Availability cluster for maximum service uptime and minute-level failover

SPECIFICATIONS

Hardware
CPU
• AMD Ryzen V1500B Quad-Core 2.2GHz
• Hardware Encryption Engine: Yes (AES-NI)
Memory
• 4GB DDR4 ECC UDIMM (Expandable up to 32GB)
Drive Bays
• 16× 3.5″ / 2.5″ SATA HDD/SSD (Drives Not Included)
• Hot Swappable Drive: Yes
• Only Synology SNV3400/3500 M.2 SSDs (Sold Separately) Can Be Used for SSD Cache
External Ports
• 2× USB3.2 Gen1 Ports
• 1× Expansion Port (Infiniband)
LAN Ports
• 4× 1GbE RJ45
• Wake on LAN / WAN: Yes
PCIe
• 1× 4-Lane x8 Slot
• Supports Network Interface Cards and M.2 NVMe SSD Adapter Cards for SSD Cache
Form Factor
• Rackmount 3U
• 4-Post 19″ Rack Installation Support
Size (H × W × D)
• 132.3 × 482 × 656.5 mm (with Server Handles)
Weight
• 17.1 kg
Cooling
• 3× (80 × 80 × 32mm) System Fans
Power
• AC Input Power Voltage: 100–240VAC
• Power Frequency: 50/60Hz, Single Phase
• Scheduled Power On/Off: Yes
Environment
• Operating Temperature: 0~35°C
• Storage Temperature: -20~60°C
• Relative Humidity: 5~95% RH
• Maximum Operating Altitude: 5,000m
GENERAL DSM SPECIFICATION
Networking Protocols
• SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP)
File Systems
• Internal: Btrfs, ext4
• External: Btrfs, ext4, ext3, FAT32, NTFS, HFS+, exFAT
Supported RAID Types
• Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Storage Management
• Maximum Single Volume Size: 108TB
• Maximum System Snapshots: 65,536×
• Maximum Internal Volumes: 64×
• SSD Cache: Read/Write Cache Support (2.5″ SATA SSD / M.2 NVMe SSD Support)
File Sharing Capabilities
• Maximum Local User Accounts: 2,048×
• Maximum Local Groups: 256×
• Maximum Shared Folders: 512×
• Maximum Concurrent SMB/NFS/AFP/FTP Connections: 1,000+
Virtualisation
• VMware vSphere
• Microsoft Hyper-V
• Citrix
• OpenStack
Security
• Firewall, Shared Folder Encryption, SMB Encryption, FTP over SSL/TLS, SFTP, Rsync over SSH, Login Auto Block, Let’s Encrypt Support, HTTPS (Customisable Cipher Suite)
Data Protection and Backup
• Hyper Backup
• Snapshot Replication (32× Maximum Replications)
• Synology High Availability
• Active Backup for Microsoft 365
• Active Backup for Google Workspace
• Active Backup for Business
Surveillance
• Maximum IP Cameras: 40×
• Total of 1,200fps @720p (H.264)
Warranty and Environment
• RoHS Compliant
